CH Die Collet

2 Sided Inverted Pyramid Pick-up Tool

This channel type is used when contact with the die cannot take place on all edges. This configuration will generate a small vacuum leak but the function of the tool is preserved. The contact is normally made on the longer edges.



Denomination Properties
Die Collet CH 2 Sided Inverted Pyramid Pick-up Tool
Maeterial Tungsten Carbide (WC)
Electr. Resistance Conductor
Size Minimum die size 0.10mm
Temp. Resistance Up to 450°C



CH 2 Sided Inverted Pyramid Pick-up Tool
